VPV Series Variable Displacement Vane Pumps

This product is suitable for metal cutting machine tools, pressure machinery, and other hydraulic systems with variable or pressure maintaining requirements.
features:
1, with pressure adjustment and flow adjustment device, pressure and flow can be adjusted.
2. When the system pressure is higher than the pressure set by the pump, the flow rate is reduced, so that the power loss is minimized, the efficiency is high, and it is safe and reliable.
3. The side plates are hydraulically balanced, which can obtain better volumetric efficiency.
4. Several new sound insulation and vibration prevention mechanisms have been adopted, with low noise and no vibration.

Get A Quote Download PDF
PREV: No previous product
NEXT: No next product
  • Specification
  • Contact Us
  • Order Code flow 0.3 5 MPa
    1800r/min L/min    		 Pressure adjustment range MPa Speed ​​range r/min Rotation direction (viewed from the shaft end) Drive power KW(HP)
    1800r/min 500r/min
      VPV1-12-20 12  0.8-2.0 800-1800 Right-hand rotation(clockwise) 0.37(0.5) 0.37(0.5)
      VPV1-12-35 1.5-3.5 0.75(1) 0.55(1)
      VPV1-12-55 3.0-5.5 1.1(1.5) 0.75(1)
      VPV1-12-70 5.0-7.0 1.5(2) 1.5(2)
      VPV1-15-20 15  0.8-2.0 0.5(1) 0.55(1)
      VPV1-15-35 1.5-3.5 1.1(1.5) 0.75(1.0)
      VPV1-15-55 3.0-5.5 1.5(2) 1.1(2
      VPV1-15-70 5.0-7.0 1.5(2) 1.5(2)
      VPV1-20-20 20  0.8-2.0 0.75(1) 0.55(1)
      VPV1-20-35 1.5-3.5 1.1(1.5) 1.1(2)
      VPV1-20-55 3.0-5.5 1.5(2) 1.5(2)
      VPV1-20-70 5.0-7.0 2.2(3) 2.2(3)
      VPV2-30-20 30  0.8-2.0 1.1(2) 0.75(1)
      VPV2-30-35 1.5-3.5 1.5(2) 1.5(2)
      VPV2-55-35 3.0-5.5 2.2(3) 2.2(3)
      VPV2-30-70 5.0-7.0 3.75(5) 3.0(5)
      VPV2-40-20 40  0.8-2.0 1.5(2) 1.1(2)
      VPV2-40-35 1.5-3.5 2.2(3) 2.0(3)
      VPV2-40-55 3.0-5.5 3.75(5) 3.0(5)
      VPV2-40-70 5.0-7.0 5.5(7.55) 4.0(5)
